Metabo HPT 36V MultiVolt 1-1/8" Rotary Hammer Review: Compact Power for Concrete Work

Introduction

Metabo HPT’s 36V MultiVolt 1-1/8 inch rotary hammer is part of a welcome trend: smaller, lighter tools that still deliver serious power. At around 7 pounds for the bare tool, this SDS Plus rotary hammer is genuinely comfortable to use overhead, which matters a lot when you are setting anchors into a ceiling for an afternoon.

Introduction

It also runs on the MultiVolt system, meaning you can power it with a battery or, if you want longer runtime, swap in the corded adapter. That flexibility is one of the main reasons this tool stands out in its class.

Performance and Specs

The numbers back up the compact size. It uses a brushless motor with a no-load speed of 0 to 1,000 RPM and an impact rate of 0 to 4,300 BPM, delivering 2.2 ft-lbs (3 joules) of impact energy. Capacity is rated at 1-1/8 inch in concrete, 1/2 inch in steel, and 1-1/4 inch in wood. Since the concrete rating is usually optimistic in real use, drilling was tested starting at 9/16 inch and working down, and performance gave nothing to complain about.

The chuck accepts SDS Plus or SDS bits, so bit selection is not a concern. With the included 4Ah battery, the total tool weight comes to 9.3 pounds and the tool length is 14-1/2 inches. Testing took place in 3-degree weather while drilling concrete, and the tool kept working without complaint.

Handling and Comfort

Vibration in the hands is very minimal, which is exactly what you want in a rotary hammer you may hold overhead for extended stretches. The two-finger trigger in the back can also be used as a one-finger trigger, and either way it feels comfortable. Everything is rubber coated, so even once the tool is covered in cement dust, it stays easy to grip with bare hands or gloves.

Three modes give you flexibility: straight drilling, drill-and-hammer, and hammer-only for chipping away at material. Being able to do multiple tasks with such a small rotary hammer is one of its best qualities.

Reactive Force Control

One of the most impressive features is what Metabo HPT calls RFC, or Reactive Force Control. If the bit binds up and the tool starts to twist in your hands, the motor shuts off automatically to help prevent injury. On a tool light enough to use overhead, this kind of safety feature can save you from getting hurt and save you time away from the job.

Dust Collection Option

There is an attachment available that adds dust collection to this rotary hammer. It would certainly help on a dusty concrete job, though it does add bulk to an otherwise very compact setup. If you regularly drill overhead or indoors, it is worth looking into.

The Case Trade-Off

The one mild criticism of this kit is the case. It is fairly large for such a small rotary hammer, which makes the whole kit look and feel bigger than it is. On the plus side, there is a lot of room inside for extra batteries, drill bits, or other accessories.

If you want a kit that tosses easily into a truck, the oversized case is a minor annoyance. If you like having spare room for accessories, it works in your favor.

Warranty

The warranty coverage is slightly different from some other Metabo HPT tools that carry a lifetime guarantee. This tool comes with a one-year warranty on the tool and a two-year warranty on the battery. It is a little surprising compared to the brand’s usual coverage, so factor that in if warranty length matters to your buying decision.

Buying Advice

Overall, this is a tool for anyone who wants serious drilling capability in a package that will not wear out their arms. Smaller tools with more power are exactly where tool technology is headed, and being able to work overhead comfortably while the tool watches for bit binding is a genuine safety and productivity win.

If you drill concrete occasionally and value light weight, this is an easy recommendation. If warranty length is a priority, just be aware it is one year on the tool rather than a lifetime guarantee.

Conclusion

The Metabo HPT 36V MultiVolt 1-1/8 inch rotary hammer combines light weight, flexible battery or corded power, three working modes, and automatic bind protection in a compact body. Performance in real concrete drilling held up without complaint, and the minimal hand vibration makes overhead work far more comfortable. With the only real drawback being a case that is larger than the tool itself, this is a strong pick for anyone who wants a small rotary hammer that punches above its size.
